Step Ten: Galaga Cocktail Table Repair or Mini
The only thing you need to know about a Galaga Cocktail table or Mini is that the inside PCB boards, controls, wiring, everything is identical to uprights, except the placement of the monitor and controls are different.
MOST IMPORTANT TO KNOW ….To enable the cocktail table game mode on any original Galaga PCB board you simply have to ground pin 21 to any ground on the 15amp Power supply or any ground in the game itself. This will cause the board to flip during the cocktail table and play inverted for player two.
Please refer to the Manual cocktail table game for placement of what is being discussed as you read through these posts. Otherwise go back to step one and trouble shoot through each post as if it were pertaining to your original cocktail table game or Mini because it is using the same parts just in different locations. Start with the Blank screen post here:
